Swift Plus

The mechanical key cutting machine for dimple, laser and tubular keys.
Swift Plus is the mechanical key cutting machine for dimple, laser and tubular keys. Easy and comfortable to use and made with resistant and durable materials, Swift Plus is reliable over time ensuring quality cutting results.

Downloads
Taggy Keys
Taggy Sequence 1
Taggy Keys
Taggy Sequence 1

Product details

  • Clamp optimized for the installation of a wide range of keys: Precise calibration means quality key cutting: Ergonomic and comfortable use: Lightweight, resistant and durable: Perfect illumination of the work station: Practical accessories area: Safe for the operator: the mains switch of the machine is thermal-magnetic, a security device that prevents that the cutter automatically turns on after an abrupt interruption and reactivation of the electric power.

Power supply:220V-230V / 50-60Hz
Cutter motor:single phase and speed
Movements:on three axes via rods and bushings
Cutting tools:HSS (high speed steel) with TiN Coating
Tool speed:50Hz: 8000 rpm (+/- 10%), 60Hz: 8000 rpm (+/- 10%)
Carriage runs:X axis: 24 mm, Y axis: 50 mm, Z vertical axis: 22 mm
Dimensions: Width: 260 mm, Depth: 285 mm, Height: 315 mm
Weight: 12 kg
